WDKY016
A Woodruff key is a small, semi-circular metal component used to secure rotating parts to a shaft. It fits into a corresponding keyway in both the shaft and the hub or gear, preventing relative movement between the two components. This ensures that the rotational force is transmitted effectively. Woodruff keys are commonly used in various mechanical assemblies, including motorcycle engines, to maintain alignment and proper function of gears, pulleys, and other rotating parts.
Manufacturer | Model | Diagram |
---|---|---|
Kiden | Aquarius 125 [KD125-G] | |
Aries 125 [KD125-J] | ||
Pisces 125 [KD125-K] | ||
Lexmoto | Assault 125 EFI [HJ125-J-E4] | View parts diagram |
Assault 125 Euro 5 [HJ125-J-E5] | View parts diagram | |
Isca 125 Euro 5 [SK125-L-E5] | View parts diagram | |
Isca 125 [SK125-L] | View parts diagram | |
Venom EFI [SK125-22-E4] | View parts diagram | |
Viper 125 [SK125-22A] | View parts diagram | |
Romet | Division 125 [SK125-22 (ROMET)] | |
Zontes | Firefly 125 [FIREFLY] | |
Javelin 125I [JAVELIN125] | ||
Mantis 125 [MANTIS125] | ||
Rocketman 125I [ROCKETMAN125] | ||
Scorpion 125I [SCORPION125] | ||
